USES AND DIMENSIONS
SEALS FOR EXTREME CONDITIONS
Energized seals are used in all conditions in which a rubber O-Ring cannot be used due to temperature, pressure or chemical compatibility
- Temperature ranging from -250° to 315° C
- Pressure ranging from 0 to 1500 Bar, fora ANSI 150 to 2500 and API 2000 to 15000
- Diameters can vary from a minimum of 15 mm up to a max of 2300 mm.
NOMINAL STANDARD SECTIONS:
| 3/32” | from 2,25 to 2,32 mm |
| 1/8” | from 3,05 to 3,15 mm |
| 3/16” | from 4,70 to 4,75 mm |
| 1/4” | from 6,05 to 6,15 mm |
| 3/8” | from 9,30 to 9,50 mm |
| 1/2” | from 12,40 to 12,60 mm |
TAILOR-MADE SOLUTIONS FOR ALL REQUIREMENTS
Made-to-mesure seals can be made for use in grooves that are of different size than those listed.
We can also produce special seals, specially designed to meet the complex needs and requirements expressed by our customers. The materials used are constantly examined and tested to ensure a finished product in line with requirements.
